Non Sterile Nylon Syringe Filter 13mm Or 25mm GC HPLC Filter Syringe

Product Details:
Place of Origin: China
Brand Name: no
Certification: ISO9001
Model Number: XNSF
Payment & Shipping Terms:
Minimum Order Quantity: 120 packs
Price: $6.00 to $15 per pack
Packaging Details: 100 pcs/pack standard export carton packaging or custom
Delivery Time: 15 to 30 days
Payment Terms: L/C, T/T
  • Detail Information
  • Product Description

Detail Information

Product Name: Syringe Filter Diameter: 13mm/25mm/33mm
Filter Medium: PP/PES/PTFE/Nylon Pore Size: 0.22μm/0.45μm/1.2μm/2μm/3μm/5μm
Housing: Polypropylene Max Operating Temperature: 60℃(140℉)
Sterilization: ETO OEM: Available
Highlight:

Non Sterile Nylon Syringe Filter

,

Nylon Syringe Filter 13mm

,

GC HPLC Filter Syringe

Product Description

Non-sterile 13mm or 25mm Nylon Syringe filter GC HPLC Syringe Filters

Nylon syringe filters are typically composed of naturally hydrophilic nylon membranes and ultrasonically-welded PP housing.These syringe filters are mostly used for handling aqueous solutions such as alkaline or organic solvent filtration of HPLC samples as they have a strong chemical resistance to alkaline samples, with a pH compatibility range of 3-14.



The nylon syringe filters from us can be made in your nominated color, either in sterile single-packaging or non-sterile barrel packaging. These filters are ultrasonically welded to guarantee no liquid or gas leakage while being subjected to high pressure. No membrane replacement or filter cleaning is required, the single-use syringe filters are a great help to lab staffs freeing them from the trivial and time-consuming preparation, and therefore are widely embraced by laboratories across the world.



The Nylon syringe filters we produce contains high performance hydrophilic Nylon membrane filter. And the Nylon membranes are manufactured in our 100,000 class facilities, while the body of the syringe filters are manufactured just a few miles away in our new Injection Molding workshop.



Specifications Available

Pore Size 0.22µm and 0.45µm
Syringe filter Diameter

13mm, 25mm and 33mm

Minimum Order Quantity 12000 pcs/ 120packs
Water flow of 0.22µm pore size 23ml/min/cm2
Bubble point of 0.22µm pore size 340kPa
Water flow of 0.45µm pore size 46ml/min/cm2
Bubble point of 0.45µm pore size 220kPa



Features

  • Hydrophilic membrane
  • Very low adsorption for pharmaceuticals and proteins
  • Good stability against organic acids and bases
  • For aqueous and slightly organic liquids with higher flow rates
  • Mechanically very stable



Applications

  • HPLC/ GC-MS small volume sample preparation, purification and prefiltering.
  • Biological products preparation.
  • Culture medium, microbial medium, buffers, additives and drugs sample filtration.
  • Strong corrosive solvents purification.



Non Sterile Nylon Syringe Filter 13mm Or 25mm GC HPLC Filter Syringe 0
